Mercedes W213 E-Class NTG 5.5 Multimedia Video interface with Digital TV/DAB Control

Xcarlink Mercedes Comand N5.5 Multimedia Video Interface with Digital Radio & Digital TV control via the original MB Comand Controller.

It features a dedicated rear camera input with dynamic parking guidelines parking guidelines that automatically displays on your screen when the car is in reverse.  It also displays dynamic parking guidelines (showing the position of the vehicle) and retains your original parking sensors.

The interface does not replace your existing system but simply offers perfect integration to maintain your OEM appearance.

Features:

• Watch any video source to your Mercedes Comand screen
• 2 x Video inputs for connecting any Video source to your original Screen.

• When combined with our Digital TV (DVB-T) or Digital Radio (DVB-T) module, our interface provides you with a fully integrated Digital Radio (DAB) or Digital TV solution where you can select stations via the Control Control knob on the NTG 5/5.1 system. This is the ideal solution if your vehicle was not fitted the DAB or if you would like to add Digital TV to your original system

• RGB input for aftermarket navigation
• 1 X Rear Camera input with automatic switching to rear camera when reverse gear is selected and Displays Dynamic Parking Guidelines (which move with the position of the steering wheel)
• Automatically dedects the rear camera signal using the vehciles CAN-BUS data

• 1 X Front Camera input with automatic or manual activation.
• 2 x Video Outputs for rear headrest screens

• Picture in Picture rear camera mode retains the original Parking sensor with the rear camera display.

• Video in motion for all connected video sources
• Switch between Mercedes display and AV input using Comand controls

• Customizable menu system for screen adjustment, parking guidelines etc


Compatibility:

Compatible with the Mercedes W213 2016 Onwards with the Comand NTG5.5 System.

Works with both the 8" and 12.2" Factory Display.

• Xcarlink v4 Multimedia Video Interface
• AV cable (2 x AV input, 1 x Reverse Camera input,  1 x Front Camer Input, 2 x AV Output)

• RGBS cable
• LVDS monitor cable
• Plug and Play Power/CAN connector


The video interface is fitted to the back of the screen via the plug and play monitor and power cables. Once installed, press and hold the Return button on your Comand controller to switch to the video inputs. The DAB DVB-T module is connected to AV1/AV2 if these devices are being installed. The interface automatically switches to rear camera when the car is in reverse gear.

Please note: For audio, the interface must be connected to the car's AUX input. If your car does not have a factory Aux input, the Aux to Bluetooth module can be added which will allow the sound to be streamed to your car system via Bluetooth without affecting your original bluetooth telephone connection.

Optional Extras:

Select from the drop down menu above to add the following options specifically designed for use with our interface.

This is the ideal solution if your vehicle was not supplied with the DAB option as standard.

DVB-T Digital TV Tuner (including antennas)

We have extensively tested this product and are confident that it will work with all factory fitted systems in the car models listed above. You do not need have a factory installed TV Tuner or have anything enabled by a Mercedes dealer. Nor do you have to have to have any optional extras installed when the car was ordered. If for any reason you are not completely satisfied or have any issues with compatibility you can return it to us for a refund.

The system is interned for passenger use only. We cannot accept any liability of any material or personal damages caused by the installation or use of this product. Therefore, installation of this product will be performed at the user full responsibility.
