Mercedes NTG4.5 HDMI Multimedia Rear Camera Interface

Category: MERCEDES
Printable Version
Mercedes NTG4.5 HDMI Multimedia Rear Camera Interface
Email
Price

£329.99

inc. VAT 20.00 % (£55.00)
SKU SKU149751
Add DVB-T Tuner
Add DAB Tuner
Add Rear Camera
Add Front Camera
Add HDMI SmartPhone Mirroring Interface
Quantity

Xcarlink Mercedes NTG4.5 Multimedia Video Interface with HDMI Input (Bulit in Smartphone mirroring )

The new  HDMI Link  interface provides all of the features of the Xcarlink v4 Multimedia Video Interface however in addition it also offers the following amazing features:

**HDMI Input** (Built In Mirroring)

The interface has a HDMI input which opens up a range of possible connectivity options with the latest digital devices.  For example a smartphone can be connected to the interface via a HDMI cable which would allow the smartphone to be mirrored on your factory fitted screen.   Giving you access to all of your apps  music, video's, web browser, messages etc,  as well as all your favorite apps such as Spotify, Twitter, Facebook, Whatsapp, Google Maps etc.   There are also a number of apps that are emerging that are designed specifically for an in car use which can all be used via this interface.

The mirroring functionality is built in to the interface so you would not need to purchase a separate mirroring interface. Simply connect an orignal TV out HDMI cable from your Smartphone to the HDMI input on the inteface. A wireless HDMI option is also available if preferred.

If you are installing a rear camera the reverse camera image is automatically displayed on a split screen with the parking sensors. In addition the interface will provide you with an OEM style solution with dynamic guidelines which move with the position of your steering wheel.

The interface does not replace your existing system but simply offers perfect integration to maintain your OEM appearance.

Features:

  • Watch any video source to your Mercedes screen, including HDMI input for connecting any AV device and smartphone mirroring.
  • 2 additional Composite AV inputs
  • ACC power output for connecting power to installed devices
  • The best rear camera integration available for your Mercedes.  The interface automatically switches to the camera when in reverse gear and supports PIP (Picture in Picture ) with your original parking sensors.
  • OEM style Rear Camera Integration with dynamic rear camera guidelines which move with the position of the steering wheel.
  • Dedicated front camera input which can be set to automatically switch to the front camera when you change from 'Reverse' to 'Drive' for a pre-defined number of seconds.
  • When combined with our DVB-T Tuner, you are able to watch high quality digital TV
  • UART input for aftermarket navigation.
  • Switch between Mercedes Display and AV/HDMI input using Comand controls
  • 5V USB Power for charging a a range of devices through the interface.
  • Comprehensive menu system which is accessed via the idrive controls to change settings, system information, rear camera guideline options, Customizable menu system for screen adjustment, HDMI mode settings, front view camera settings, activation settings etc.

Compatibility:

The interface is compatible with Mercedes vehicles from 2011 onwards with the NTG4.5 Comand System. It is suitable for both the 5 inch and 7 inch screens with the round Fakra connector:

·  B-Class (W246) 2011>

·  C-Class (W204) 2011>

·  E-Class (W212) 2011>

·  E-Class Coupe (C207) 2011>

·  CLS-Coupe (C218) 2011> Onward

·  GLK-Class (W204) 2011>

·  ML-Class (W166) 2011>

·  SLK-Class (R172) 2011>

·  SL-Class (R231) 2012>


The kit includes the following:
  • Xcarlink Mercedes V4 Multimedia interface with HDMI input and Built in Mirroring.
  • HDMI Sub-Board & HDMI Cable
  • AV cable (2 x AV input, 1 x Reverse Camera input, 2 x AV Output for rear screens)
  • Farkra LVDS monitor cable
  • Power cable
Installation

The video interface is fitted to the video cable which connects to your screen/head unit.     Includes a power cable to connect to 12v and Ground and CAN High/Low.   Once installed, press and hold the 'Return'  button on your Comand controller to switch to the video inputs. The interface automatically switches to rear camera when the car is in reverse gear, and to front camera if required.  Detailed on Screen menu functions allow may settings to be altered.

Please note: For audio, the interface must be connected to the car's AUX input. If your car is equipped with a factory AMI option an AMI converter can be purchased from our site.

Optional Extras

Select from the drop down menu above to add the following options specifically designed for use with our interface.

DVB-T Digital TV Tuner (including antennas)

Watch digital TV anywhere you go in your car. This high quality digital tuner is supplied with dual amplified window mount antennas for superior reception, especially when on the move. There is also a USB input for playback of audio and video files.

Rear Camera

The rear camera is specifically designed to fit the boot lid handle of the Mercedes or a Universal camera is fitted to the number plate light. Please select from the required model from the drop down menu.


The front camera is specifically designed to fit the diamond grill on the front of the car.

Wireless HDMI Smartphone MIrroring.

Mirror your smartphoen wirelessly with the dual Band HDMI Mirroring module

MDI to  2 RCA Aux IN adapter

Convert your original Mercedes MDI connectino to an Aux input to allow the audio to be routed from the interface to your origianl system.

Money Back Guarantee:

We have extensively tested this product and are confident that it will work with all factory fitted systems in the car models listed above. You do not need have a factory installed TV Tuner or have anything enabled by a Mercedes dealer. Nor do you have to have to have any optional extras installed when the car was ordered.

The system is interned for passenger use only. We cannot accept any liability of any material or personal damages caused by the installation or use of this product. Therefore, installation of this product will be performed at the user full responsibility.
